LIGHT SOURCE

Osram High Power 4in1 40w*37pcs
Life Span: ＞ 50,000 hours

OPTICAL SYSTEM

Zoom angle: 4° - 60°

Lens：High-quality optical lens

COLOR SYSTEM

RGBW 4in1 Color Linear Mixing

EFFECTS

All-optical domain dimming, grade dimming accuracy
Each LED and color can be control alone,variety of gorgeous effects
Lens can be 360° unlimit rotatable at variable direction and speed

MOVEMENT PARAMETER

Pan 540°, Tilt 270°

Movement quicker, smoother and more mute.

CONTROL AND PROGRAMMING

Control Channel: 22/36/133/147/170 five channel modes

Protocol: Standard DMX512,Random,Sound,Auto,Built-in,Optional

Menu display: LCD display,Chinese and English language; menu available to display 180° reversely.

Power Connection: PowerCon-input/output

DMX Signal Connection: 5-pin & 3-pin XLR input/output

ELECTRONIC CONTROL TECHNOLOGY
Fixture reset is controlled through menu or light console

0-100% dimmer

Constant current drive mode

DMX channel level monitoring

Fixture information query

Initial brightness setting for all colors

POWER SUPPLY

AC110-240V/50-60Hz

Input Power: 1500W

Overcurrent, overvoltage and overheating protection

WORKING POSITION

Any safe position to install

WORKING TEMPERATURE

﹣10℃ - 45℃

PHYSICAL

Fixture:

Net Weight: 24.8 kgs

Product Dimension: 496*293*590mm

IP RATE

IP20

MISC/OPTIONS
User manual: included
Power cable: included
DMX cable: included
Safety cable: included
Mounting clamp: not included
Flight case: not included
