LIGHT SOURCE
High power custom GF 700W White LED Mould
Color T: 8000K
CRI: ≥90
Life span: 20000 hours
OPTICAL SYSTEM
Zoom Angle: 4°-48°
Lens: High-quality optical lens
COLOR SYSTEM
Color wheel: 6colors + white + CMY +CTO + Framing
CTO From 3200-7200K adjustable
Half color effect, rainbow effect with adjustable speed
Step/linear conversion color optional
EFFECTS
Prism：3-facet prism, reversible rotation with adjustable speed
Fixed gobo wheel：1 fixed pattern wheel, including 8 metal patterns and white circles, with pattern shaking and two-way flowing water effect;
Rotating gobo wheel：1 rotating gobo wheel, including 7 easy-to-change glass self-rotating gobo wheels and white circles, with pattern shaking, positioning, and two-way variable speed rotation effects
Framing Cutting system 4 cutting pieces form a stable and fast cutting module, which can be combined into a variety of shapes, each cutting piece can be independently closed, and the cutting module can be rotated 90° as a whole
Strobe：1-25 times/second change, strobe effect of various modes and speeds;
MOVEMENT PARAMETER
Pan 540°, Tilt 270° 16Bit
Movement quicker, smoother and more mute
CONTROL AND PROGRAMMING
Control Channel: 38/40 control channel modes
Protocol: Standard DMX512,Random,Sound,Auto,Built-in,Optional
Menu display: LCD display,Chinese and English language; menu available to display 180° reversely.
Power Connection: Seetronic Waterproof PowerCon-input/output
DMX Signal Connection: Seetronic Waterproof 3-pin XLR input/output
Art-Net Connection ： Seetronic Waterproof Art-Net input/output
ELECTRONIC CONTROL TECHNOLOGY
Fixture reset is controlled through menu or light console
0-100% dimmer
Constant current drive mode
DMX channel level monitoring
Fixture information query
Intelligent fan speed adjustment
Initial brightness setting for all colors
POWER SUPPLY
AC110-240V/50-60Hz
Power Consumption: 850W
Overcurrent, overvoltage and overheating protection
WORKING POSITION
Any safe position to install
WORKING TEMPERATURE
﹣10℃ - 45℃
PHYSICAL
Fixture:
Net Weight: 28.5 Kgs
Product Dimension: 415*240*766mm
IP RATE
IP20
MISC/OPTIONS
User manual: included
Power cable: included
DMX cable: included
Safety cable: included
Folding clamp: included
Flight case: not included
