LIGHT SOURCE

TX High Power 4in1 RGBL 120w*5pcs + 120pcs RBG LEDs

Life Span: ＞ 50,000 hours

OPTICAL SYSTEM

Zoom angle: 3-45°

Lens：High-quality optical lens

COLOR SYSTEM

RGBL 4in1 Color Linear Mixing

EFFECTS

All-optical domain dimming, grade dimming accuracy
Each Head and LED and color can be control alone,variety of gorgeous effects

MOVEMENT PARAMETER

Pan 60° continuous rotation

Tilt 220° continuous rotation

Movement quicker, smoother and more mute.

CONTROL AND PROGRAMMING

Control Channel: 41/41/75/85/170 control channel modes

Protocol: Standard DMX512,Random,Sound,Auto,Built-in,Optional

Menu display: LCD display,Chinese and English language; menu available to display 180° reversely.

Power Connection: PowerCon-in/out

DMX Signal Connection: 3-pin XLR input/output

ELECTRONIC CONTROL TECHNOLOGY
Fixture reset is controlled through menu or light console

0-100% dimmer

Constant current drive mode

DMX channel level monitoring

Fixture information query

Initial brightness setting for all colors

POWER SUPPLY

AC110-240V/50-60Hz

Input Power: 1000W

Overcurrent, overvoltage and overheating protection

WORKING POSITION

Any safe position to install

WORKING TEMPERATURE

﹣10℃ - 45℃

PHYSICAL

Fixture:

Packing Weight: 30 kgs

Packing Dimension: 1000*192*350mm

IP RATE

IP20

MISC/OPTIONS
User manual: included
Power cable: included
DMX cable: included
Safety cable: included
Mounting clamp: not included
Flight case: not included
